22" - 55" PCAP Touch Screens Displays



This range of PCAP touch screen displays starts at 22" and runs up to 55". The price includes a wall mount, 12 Months CMS Subscription & Delivery to site.

Discounts available for multiple orders.

Contact the team on +44 (0)1225 282 117 or This email address is being protected from spambots. You need JavaScript enabled to view it. for further details.

All prices exclude VAT and installation.





  • Touch CMS

    The screen can still be used as a touch monitor if you connect your own PC or you can run your own touch software from the integrated Dual OS PC board with Windows and Android. However you can use our ground breaking new Touch Cloud Management System that puts you in control as you create, deploy and touch your very own content on screen. First, you create your custom layouts with our user friendly software that requires no knowledge of coding to use. Then deploy the content from your PC direct to your Touch Screens in a matter of seconds. Now all that is left to do is touch as you let your content do the talking about your brand, company, service or product.
  • Dual OS

    Experience the most versatile commercial touch screen on the market. With both Android and Windows operating systems installed on the integrated PC it cannot be beaten on flexibility. Seamlessly switch from your Windows desktop to the Android apps; this screen has it all in one convenient package. A Windows license will need to be purchased separately.
  • PCAP Touch

    State of the art Projected Capacitive interactive technology offers the most responsive and sensitive touch experience available. Designed for commercial applications, PCAP touch technology works by fixing a sensor grid between a layer of cover glass and the LCD panel, when a finger touches the glass the grid detects the coordinates of the touch point. Unlike other touch technologies PCAP is not affected by dust or debris on the screen surface, allows for up to 10 touch points and offers superior optical quality.
  • 10 Touch Points

    Having up to 10 touch points allows for a wider variety of applications than ever before. This kind of functionality allows you to manipulate images, zoom in an out as well as perform many other touch gestures; much like you would with a domestic tablet. It also allows for multiple users interacting with the screen at one time.
  • LED Backlight Technology

    The LED backlight used is not only eco-friendly but also ensures the display has enhanced brightness and contrast. This technology increases the lifespan and reduces the power consumption by around 30%. This form of light technology is mercury free; safeguarding this screen’s eco friendliness.
  • 24/7 Usage

    Built with commercial grade panel and components these displays are designed to run 24/7 in constant use; unlike domestic tablets. The panel has a lifespan of over 50,000 hours of continuous use. They can also be used in landscape or portrait orientation.
  • Attach External Devices

    Although the screens have an integrated PC with two operating systems, there is also a possibility to attach external devices if required. Simply connect your device to the screen, via VGA or HDMI (for the video signal) and USB (for the touch functionality). The screen will then serve as your computer monitor and the touch functionality controls the cursor, essentially acting as your mouse.
  • 1




Product Code AO22E AO32E AO43E AO50E AO55E
Diagonal Size (inch) 22" 32" 43" 50" 55"
Resolution 1920x1080
Display Area (mm) 478x269 701.4x395.8 942.5x530.5 1076x606 1211x682
Pixel Pitch (HxW mm) 0.253x0.253 0.368x0.368 0.495x0.495 0.576x 0.576 0.634x 0.634
Aspect Ratio 16:9
Unit Size (WxHxD mm) 590x383x50 814x503.8x69 1048.9x636.9x64.7 1186.6x716.6x65 1319.6x790.6x65
Package Size (WxHxD mm) 725x525x210 955x630x230 1188x772x220 1350x865x270 1485x930x220
VESA Holes (mm) 100x100 400x200
Net Weight (Kg) 9.2 15.1 24.1 30.6 36.5
Gross Weight (Kg) 11.65 18.35 28.4 36.65 45.2
Brightness (cd/m2) 450
Colour 16.7M
Viewing Angle 178°
Contrast Ratio 5000:1
Input Voltage AC110~240V (50Hz~60Hz)
Working Temperature 0°C to 50°C
AV Signal Inputs VGA, HDMI
CPU Intel® Atom™ (Quad-core) x5-Z8350 Processor (2M Cache, up to 1.92 GHz)
RAM 2GB (DDR3L-RS 1600MHz)
Instruction Set 64-bit
Graphic Engine Intel® HD Graphics 400 (8th Gen, Supports DirectX11.2, OpenGL4.4 and OpenCL 2.0)
Hard Drive/Internal Memory (eMMC) 32GB
USB 2 x USB 2.0
LAN 10/100M Ethernet
Wi-Fi 802.11b/g/n
OS Android 5.1.1
Windows® 8 /8.1 64-bit, Windows® 10 64-bit,
Windows 10 IoT Enterprise 64bit (licence purchased separately)
Other No accessible buttons or controls
Accessories Remote Control, User Manual, Power Cable, USB to USB Cable, Wi-Fi Aerial



  • 22" PCAP Touch Screen Display
  • £850

  • Includes Wall Mount
  • 12 months CMS Subscription
  • Delivery
  • 32" Touch Screen Display
  • £1300

  • Includes Wall Mount
  • 12 months CMS Subscription
  • Delivery
  • 43" Touch Screen Display
  • £1550

  • Includes Wall Mount
  • 12 months CMS Subscription
  • Delivery
  • 50" Touch Screen Display
  • £1800

  • Includes Wall Mount
  • 12 months CMS Subscription
  • Delivery
  • 55" Touch Screen Display
  • £2200

  • Includes Wall Mount
  • 12 months CMS Subscription
  • Delivery
